Using a Laser for Implant Uncovery

Traditionally, uncovery of dental implants utilizes a scalpel blade or tissue punch to incise through the soft tissue, which exposes the cover screw of the implant. Unfortunately, this traditional technique can cause post-operative discomfort and bleeding.

One alternative to using a scalpel for uncovery includes electrosurgery, which decreases post-operative discomfort and bleeding by cauterizing tissue. However, it can potentially elevate the temperature around the implant, resulting in bone loss.

Another option for uncovery is laser, which is used for procedures such as soft-tissue crown lengthening, troughing, gingivectomy, and esthetic recontouring. The laser is ideal for implant uncovery and tissue modification around implants because there is little to no bleeding, and it reduces post-op pain.

This step-by-step visual essay shows how to use a laser for implant uncovery.

Frontal view of the patient. Teeth #7 and #11 were prepared for crowns and implants were placed in #8 and #10.
Figure 1: Frontal view of the patient. Teeth #7 and #11 were prepared for crowns, and implants were placed in #8 and #10.
Mitrani laser implant recovery 02
Figure 2: Occlusal view of the patient. The implant on #8 had already been uncovered, and a healing abutment was in place.
Mitrani laser implant recovery 03
Figure 3: A surgical guide marks the location of the implant so the soft tissue on top of it can be removed.
Mitrani laser implant recovery 04
Figure 4: A Waterlase laser with a MZ6 tip is used.
Mitrani laser implant recovery 05
Figure 5: The tip of the laser precisely removes only the necessary soft tissue above the implant to expose the cover screw/healing abutment.
Mitrani laser implant recovery 06
Figure 6: The result after soft tissue is removed.
Mitrani laser implant recovery 07
Figure 7: A view of the area after the healing abutment is removed.
Mitrani laser implant recovery 08
Figure 8: Impression copings are placed immediately following the uncovery to make the provisional impression.
Mitrani laser implant recovery 09
Figure 9: Occlusal post-operative view after seven days.
Mitrani laser implant recovery 10
Figure 10: Seating the provisional implant-supported restoration.
Mitrani laser implant recovery 11
Figure 11: Provisional restoration with composite-filled access screw.

This is a simple, step-by-step technique for using the laser for implant uncover. An advantage to using a laser is that the impression can be made immediately after the uncovery, and post-operative discomfort and bleeding are minimized.
